2097TRWRW - Radiant Self Test TR WR GFI 20A 125V WH

Legrand-Pass & Seymour

$36.69 (Each)
$36.69 (Each)
$366.90 (Per 10)

In-Stock: 46 available locally (Nacogdoches, TX ) ( change location)

Buy Now

QTY:

Each

Overview
Specifications
Current Stock
Alternate Items

Overview

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Help Improve Our Data

Quick Specs

Catalog Number: 2097TRWRW Vendor Code PAS
Manufacturer: Legrand-Pass & Seymour
Manufacturer's Part Number: 2097-TRWRW
Description: Radiant Self Test TR WR GFI 20A 125V WH
Self-Test Duplex Receptacle, 20 A, 125 V, 2 Poles, #14 to #10 Awg Compatible Wire Size, Control Circuit Actuator, Back and Side Wired Connection, 60 HZ, 1.73 In Width, 4.20 In Height, Thermoplatic Material, White, 0.025 Sec Trip Time, Weather Resistant, 0.2800 LB
Slang Terms: Suggest a New Term
Categories: Gen Purpose Wiring Devices - Gen Purpose Recept & Surge Pro Mark as Incorrect
Suggest a New Category
Classification: Residential Gfci Devices
UNSPSC: 39121406 - Electrical receptacles
UPC/EAN/GTIN: 785007036107 / 0785007036107 / 00785007036107
Weight per unit: 0.275 (lbs/each)

Price & Packaging

Minimum Order Quantity: 1
Unit: $36.69 (Each)
Standard Packaging: $366.90 (Per 10)

Stock Availability

Nacogdoches: 46 (Check another store)
All Stores: 1,968

Resources

Images
: 2097TRWRW - Large Image
: 2097TRWRW - Large Image
: 2097TRWRW - Large Image
: 2097TRWRW - Large Image
: 2097TRWRW - Small Image
: 2097TRWRW - Large Image
: 2097TRWRW - Large Image
: 2097TRWRW - Large Image
: 2097TRWRW - Large Image
: 2097TRWRW - Large Image
: 2097TRWRW - Large Image
Other Links
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
: 2097TRWRW - Other
Attachments
: 2097TRWRW - Specification Sheet
Brochures
: 2097TRWRW - Brochure

Suggest Substitute Item

Help Improve Our Data

Edit Mode: Please login to suggest improvements for this item.

Specifications

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Help Improve Our Data

Features

Actuator: Control Circuit
Amperage Rating: 20
Connection: Back and side wire
Current Rating: 20 A
Interrupt Rating: 4 to 6 mA
Material: Thermoplatic
Number Of Gangs: 1.0
Number Of Wires: 3
Poles: 2
Voltage Rating: 125

Material, Color, and Finish

Color: White
Finish: Matte

Dimensions and Weight

Height: 4.20 in
Length: 1.03
Width: 1.73

Descriptions

Description: RADIANT SELF TEST TR WR GFI 20A 125V WH
Extra Long Description: P&S 2097TRWRW RADIANT SELF TEST TR
Features: The radiant(R) collection is a step up from the standard with simple, classic options in wiring devices, home automation controls and screwless wall plates that complement today's homes.The self-test GFCI conducts an automatic test every three seconds, ensuring it's always ready to protect. If the device fails the test, the indicator light flashes to signal that the GFCI should be replaced. It also has our proven SafeLock(TM) Protection feature: if critical components are damaged and protection is lost, po
Long Description: Self-Test Duplex Receptacle, 20 A, 125 V, 2 Poles, #14 to #10 AWG Compatible Wire Size, Control Circuit Actuator, Back and Side Wired Connection, 60 Hz, 1.73 in Width, 4.20 in Height, Thermoplatic Material, White, 0.025 sec Trip Time, Weather Resistant, 0.2800 lb
Product Type: Self-Test Duplex Receptacle
Short Description: 20 A, 125 V, Self-Test Duplex Receptacle, White, GFCI, TR, 3 Wires
Special Features: 10 kA Short Circuit Rating;20 Amp Feed-Thru Capacity

Additional Information

Actuator Type: Control Circuit
Compatible Wire Size: #14 to #10 AWG
Connection Type: Back and Side Wired
Indoor/Outdoor: Both
Mounting Type: Box
Outlet Type: Tamper-Resistant, Weather-Resistant, GFCI
Package Quantity: 1 CT;10 PK
Receptacle Type: Self Test Duplex
Resistance Properties: Weather Resistant
Standards Met: cULus Listed;UL Listed;fsUL Listed;UL 94 v2;UL498;Federal Specifications
Trip Range: 4 to 6 mA
Trip Time: 0.025 sec
Trip Type: .025 Second Nominal
Voltage: 125.0 V
Wall Plate Included: YES

Manufacturer Information

Brand: Pass & Seymour
Manufacturers Part Number: 2097TRWRW
GTIN: 00785007036107
UPC: 785007036107

Taxonomies, Classifications, and Categories

Category Description: Residential GFCI devices
Type: Outlet

Trade Size

Amperage: 20.0

Packaging

Weight: 0.2800 lb
Weight per each: 0.275
Carton: 1
Package: 10

Uses, Certifications, and Standards

Application: Residential;Commercial
Environmental Conditions: 95% Humidity, UL 94 V2
Frequency Rating: 60 Hz
Nema Rating: 5-15R
Operating Temperature: -35°C to +66°C
Standard: UL, CULUS, cULus, UL Listed, FSUL
